Hantech H-Pro 12000 BTU/h Split Air Conditioner Kit + 3m Pipe + Bracket - HNT-WP12VMCL/S
Product number:
AC10710054
In stock
Delivery by 29.09.2026
HANTECH Split Air Conditioner 12,000 BTU: A top-brand product featuring high-quality inverter technology, R32-refrigerant, and eco-friendly features for a comfortable indoor climate.
€799.00
incl. 19% VAT
Collection possible from our Karlsruhe site (Wikingerstraße 10), Mon–Fri 09:00–12:00 and 13:00–17:00
Scope of delivery
HANTECH Split Air Conditioner 12,000 BTU 3.4 kW
This version includes 1 × Hantech H-Pro 12K indoor unit – HNT-WP12VMCL/I and 1 × Hantech H-Pro 12K outdoor unit + 3 m Kit – HNT-WP12VMCL/O (12,000 BTU/h cooling capacity).
TOP BRAND PRODUCT
Pre-filled with R32 refrigerant for approx. ∼ 3 m of piping. Operation requires a 230 V household power supply near the outdoor unit. The indoor unit is powered by an electrical cable connected to the outdoor unit. Thanks to the latest inverter technology with precise speed control, low power consumption, and continuous room temperature monitoring, a comfortable, consistent climate is guaranteed. Evacuation of the lines by an HVAC technician is mandatory for long-term, trouble-free operation.
9,000 BTU
- Room size
up to 30 m² - Indoor unit
dimensions 790×275×192 mm
12,000 BTU
- Room size
up to 45 m² - Indoor unit
dimensions: 790 × 275 × 192 mm
18,000 BTU
- Room size
up to 60 m² - Indoor unit
dimensions: 920×306×195 mm
24,000 BTU
- Room size
up to 80 m² - Indoor unit
dimensions: 1,100 × 333 × 222 mm
Technical Specifications
| IN ACCORDANCE WITH EU REGULATION 626/2011 | HNT-09-HPRO | HNT-12-HPRO | HNT-18-HPRO | HNT-24-HPRO |
|---|---|---|---|---|
| Circuit | ||||
| Connections / Threads | 1/4 3/8 | 1/4 3/8 | 1/4 3/8 | 1/4 1/2 |
| Internal | 19 dB(A) and above | 19 dB(A) and above | 22 dB(A) and up | 24 dB(A) and up |
| Product Dimensions | ||||
| Outdoor Unit Dimensions (W x H x D) | 712 × 459 × 276 mm | 712×459×276 mm | 853×602×349 mm | 920×699×380 mm |
| Outdoor Unit Weight | 22 kg | 22 kg | 35 kg | 40 kg |
| Energy Label |  |  |  |  |
1*) Annual energy consumption (kWh/year). Based on standard test results. Actual consumption depends on usage and the appliance’s location.
2*) Refrigerant leaks contribute to climate change. Refrigerants with a lower GWP () contribute less to global warming in the event of a leak than those with a higher GWP (). This system contains a refrigerant with a GWP of 675. Thus, a leak of 1 kg of this refrigerant would have an impact on global warming 675 times greater than that of 1 kg of CO₂, over a period of 100 years. Do not perform any work on the refrigeration circuit or disassemble the unit—always consult qualified personnel.
GWP: 675
Refrigerant charge: 0.49 kg
CO₂ equivalent: 0.331 t
HANTECH FEATURES
GOLD COATING
The patented HANTECH™ gold coating with nano-titanium oxide applied to the evaporator is a self-cleaning, antibacterial alloy that offers improved corrosion resistance. As a result, energy efficiency remains virtually unchanged even after 8 years. Organic pollutants are broken down and odors are neutralized.
Wi-Fi
APP Control
Conveniently control the air conditioner and access all available functions and settings while on the go. For example, you can pre-cool the room a few minutes before arriving so you can walk into a comfortably tempered space. In addition to the infrared remote control, the unit can also be controlled via your home Wi-Fi network without requiring an internet connection.
Smart Home
Intelligent Climate Control with Hantech H-Pro: Smart Home Integration
The Hantech H-Pro split air conditioner brings state-of-the-art smart home technology into your home. With smart home integration, you can control your indoor climate conveniently and intuitively, no matter where you are.
Remote Control via App: Using the user-friendly app, you can control the air conditioner anytime, from anywhere. Adjust the temperature, change the operating modes, or turn the air conditioner on and off—all with just a few taps.
Voice control: The Hantech H-Pro is compatible with popular voice assistants such as Amazon Alexa and Google Assistant. Simply say the command you want and enjoy the convenience of voice control.
Automation: Create custom scenarios and automations. Have the air conditioner turn on automatically when you get home, or set a schedule to optimize energy consumption.
Real-Time Monitoring: Keep an eye on your indoor climate. The app offers real-time monitoring and reports on temperature, humidity, and energy consumption, so you always have control over your indoor climate.
New Design
Small gap dimensions ensure efficient, quiet operation and a high-quality design. A large louver allows for wide, draft-free air distribution and improves comfort and energy efficiency—ideal for a consistent indoor climate in any situation. The included USB Wi-Fi dongle enables a Wi-Fi connection, allowing you to conveniently control the device via the app on your smartphone or tablet.
MODES
Cooling
The classic cooling mode efficiently lowers the room temperature, ensures a comfortable indoor climate, and operates in an energy-saving manner.
Heating
Heating mode allows for quick and efficient heating of rooms and ensures comfortable temperatures even on cold days.
Ventilation
This mode ensures a constant exchange of air, improves air quality, and reduces stagnant air in the room—even without active cooling or heating.
Dehumidification
The dehumidification function lowers humidity, prevents mold, and creates a more comfortable indoor climate.
Turbo Mode
H-PRO’s Turbo Mode activates maximum power to cool or heat rooms particularly quickly.
Supersilence
Supersilence mode reduces operating noise to a minimum, ensuring particularly quiet and peaceful nights.
ECO Mode
H-PRO’s ECO Mode saves energy and significantly reduces operating noise.
Gentle Wind
Say goodbye to cold drafts; 1,422 micro-holes create a soft and even airflow.
Self-Cleaning
How It Works
1. Freezing
Freezing the
heat exchanger to
trap particles
2. Thawing
The system is defrosted to loosen and rinse away the dirt
3. Drying
Preparation and
drying
of the heat exchanger
4. High-Temperature
Harmful microorganisms are
killed for 30 minutes at 56 °C
Special Features
iFeel
The room temperature is measured directly by the remote
control. Enjoy consistent
temperatures throughout the entire room
Timer
The 24-hour timer is a convenient feature of the H-PRO that turns the air conditioner on or off at the desired time
Health
Ionization of the room
air; charged ions effectively bind pollutants and thus purify the air—simply during operation.
Sleep
Sleep mode prevents the room from getting too cold overnight and also ensures quiet operation.
Mildew
This mode ensures
that the indoor unit dries out after operation to prevent mold growth.
8°C Heat
The H-PRO has built-in frost protection; your rooms will always stay above 8°C—completely automatically.
Display
The LED display integrated into the unit is backlit, easy to read, and can be turned off completely if desired.
Smart
The HANTECH H-PRO can be conveniently controlled via an app for Android and iOS using the included Wi-Fi stick.
Installation
More space for piping and condensate pumps
Easy removal from the mounting plate
Convenient access for electrical connections
More space for connections and leak testing
Leak testing of the connections is easily possible after installation—a working clearance of up to 120 mm is available.
Maintenance
Leak test while installed
Thanks to the mounting plate with an integrated spacer, the cables can be easily checked for leaks even after installation.
Circuit Board Replacement
Easily replaceable electronics—quick access in the event of a malfunction or defect in the main circuit board of the indoor unit
FUTURE-PROOF, ECO-FRIENDLY
R32
Why switch to R32?
Under EU Regulation CE 517/2014, R410A is being phased out and replaced with non-fluorinated gases (F-gases) such as R32 for environmental reasons. Smaller charge quantities are required, and the gas can be more easily recycled and reused.
R32 It is environmentally friendly
Positive effects include no impact on the ozone layer and a reduced contribution to global warming. A transition period for R410A will be granted starting in 2017—as of 2025, imports for systems with a charge of less than 3 kg will be prohibited. As a simple refrigerant, rather than a compound, R32 can be easily recycled and reused. Thus, it is environmentally friendly
Advantages over
R410A refrigerants
- ∼70% lower global warming potential
- 0% ozone depletion potential
- Future-proof
- Lower global warming potential
HANTECH’s
Vision for the Future
Today, protecting the environment is one of society’s most important challenges. Both end users and manufacturers are doing their best to protect the environment as much as they can. As one of the pioneers in air conditioning manufacturing, HANTECH is committed to “R32.”
Effort for HVAC Technicians
Since “R32” requires no extra effort and is as easy to install as “R410A,” there will be no additional costs. On the contrary, “R32” is more cost-effective because it requires less refrigerant for the same cooling capacity.
scope of delivery
HANTECH Split Air Conditioner 12,000 BTU 3.4 kW
- 1x HANTECH Indoor Unit H-PRO 12,000 BTU 3.4 kW
- 1x Outdoor unit compatible with HANTECH H-PRO 12,000 BTU 3.4 kW
- 4x vibration dampers / rubber pads for outdoor unit
- 1x Electrical connection cable, 3 m
- 1x Instruction manual
- 1x remote control
- 1x Mount for remote control
- 1x mounting plate for indoor unit
- 1x Mounting bracket for the outdoor unit
- 1x 1/4 copper pipe, 3 m
- 1x 3/8 copper pipe, 3 m
- 1x condensate drain hose
- Outdoor unit pre-filled for up to 3m of piping
Note: The indoor and outdoor units (including accessories) are shipped in separate packages. These may arrive at different times. In this case, please wait until the entire order has been delivered. If you have any questions, we’re happy to help.
Product videos
Installation Video
The video demonstrates the simple installation of the Hantech H-Pro air conditioner. With step-by-step instructions, installation is quick and easy. Perfect for anyone looking for an efficient and user-friendly cooling solution.
Product Video
This video introduces the Hantech H-Pro air conditioner. Discover its innovative features and elegant design, which ensure efficient and powerful cooling. Ideal for modern homes and offices.
Technical Data
Net Weight
22
Width
712
Height/Lenght
459
Depth
276
Product Warranty
3
Cooling Capacity
11600
Heating Capacity
11703
Capacity Range (Cooling)
3412 BTU/h ~ 12863 BTU/h
Capacity Range (Heating)
3412 BTU/h ~ 13000 BTU/h
SCOP
4
SEER
6.1
Temperature Setting Range
16°C ~ 31°C
Operating Temperature Range (Cooling)
53°C ~ -15°C
Operating Temperature Range (Heating)
30℃ ~ -20℃
Sound Power Level dB(A)
60
Sound Pressure Level dB(A)
50
Refrigerant Pipe Diameter (Gas)
3/8" - (Φ9.52)
Refrigerant Pipe Diameter (Liquid)
1/4" - (Φ6,35)
Refrigerant / Fluid
R32
Recommended Maximum Application Area m²
45
Installation Pipe Maximum Height
10
Installation Pipe Maximum Length
25
Net Weight
8
Width
790
Height/Lenght
275
Depth
192
Product Warranty
3
Cooling Capacity
12000
Heating Capacity
12000
Capacity Range (Cooling)
3412 BTU/h ~ 12863 BTU/h
Capacity Range (Heating)
3412 BTU/h ~ 13000 BTU/h
SCOP
4
SEER
6.1
Temperature Setting Range
16°C ~ 31°C
Operating Temperature Range (Cooling)
53°C ~ -15°C
Operating Temperature Range (Heating)
30℃ ~ -20℃
Sound Power Level dB(A)
32
Sound Pressure Level dB(A)
22
Refrigerant Pipe Diameter (Gas)
3/8" - (Φ9.52)
Refrigerant Pipe Diameter (Liquid)
1/4" - (Φ6,35)
Refrigerant / Fluid
R32
Recommended Maximum Application Area m²
45
Installation Pipe Maximum Height
10
Installation Pipe Maximum Length
25
Manufacturer information (GPSR)
Disposal of waste electrical and electronic equipment
Electrical appliances do not belong in household waste. You can return old appliances free of charge to municipal collection points or register them with us for take-back. The crossed-out wheelie bin means the appliance must be collected separately.
