PV Set - 16740Wp Complete PV System with 10 kWh-Battery | Wi-Fi Stick | JA Solar 465W Glass-Glass Black Frame Modules
Optional add-ons for this set
Not included in the scope of delivery
16,740 wp complete PV system with 10 kWh storage unit and 465 W JA Solar JAM54D40 LR Black Frame
This version includes 36 × JA Solar 465W Glass-Glass Black Frame - JAM54D40-465/LR, 2 × Growatt SPF 6000 ES Plus Off-Grid Hybrid Inverter and 2 × Growatt AXE 5.0L-C1, LV 5 kWh Battery Module (16,740 Wp module output, 10 kWh storage capacity).
Maximum Watt Output
- 16,740 wp with 465 wp/module
Storage capacity
- 10 kWh s at 5 kWh per block
Max. Module Efficiency
- 23.3%
16.74 kW PV system with 10 kWh storage and 465 W JA Solar JAM54D40 LR Black Frame
Increase your energy independence with our high-performance solar system. Here you’ll receive a complete set with guaranteed compatible components and German-speaking customer service that’s happy to advise you.
You’ll receive premium solar panels from JA Solar. The 465W JA Solar JAM54D40 LR Black Frame model stands out for its black design. The module is glazed on both the front and back, which largely prevents fires. Additionally, the panel easily withstands snow loads of 5,400 Pa and wind loads of 4,000 Pa and comes with a manufacturer’s warranty of 25 years on the product and 30 years on performance. It combines the latest technology with an elegant design.
The set is complemented by the SPF 6000 ES Plus inverter from Growatt. With 8,000 W of solar input power and 6,000 W of output power, 93% efficiency, and two MPPT trackers, it offers the perfect solution for your photovoltaic system. These trackers ensure that the solar panels’ optimal power point is found, guaranteeing that the maximum available power is extracted from the panels. Up to 6 devices can be operated in parallel. Control and monitoring can be performed either via an app or a web platform. The required Wi-Fi dongle and installation code (Germany; others available upon request) are included in the scope of delivery.
Highlight – Configurable Grid or Solar Input Priority
Decide whether to prioritize solar energy or grid power—ideal for regions with unstable power supplies or for promoting renewable energy. This feature enhances grid independence, ensures a reliable energy supply, and enables energy management that’s perfectly tailored to your needs. In addition, the inverter offers time-controlled charging and precise power control for efficient energy management. Charging times can be optimally adjusted to match daylight hours to maximize battery capacity. Power control allows you to adjust energy production and ensures a stable supply even when demand fluctuates.
The set is rounded out by the Growatt AXE storage system, with a capacity of 5 kWh per storage block. This allows you to use affordable, self-generated electricity even at night.
The Growatt AXE 5.0L-C1 LV battery is a modular LiFePO4-storage system with a capacity of up to 50 kWh. Thanks to its wireless, stackable installation and automatic module detection, it’s easy to expand. It offers high safety, a long service life, and supports remote diagnostics as well as firmware updates.
Your Benefits
Independence
Protect yourself so you’re no longer dependent on the public grid. Save on electricity costs and do your part to protect the environment.
Financial Security
Protect yourself against rising energy costs and inflation by investing in our solar kit, which offers sustainable financial benefits through long-term savings.
Cutting-Edge Technology and Long Warranty
All components are covered by the manufacturer’s warranty and represent the latest state-of-the-art technology.
Monitoring and Control
Elegant design and smart control via a web app or smartphone.
Technical Specifications
| Specifications | Growatt SPF 6000 ES Plus |
|---|---|
| rated power | 6000 W (6 kW) |
| Max. Power | 8,000 W |
| Input Voltage | Max. 500 VDC |
| efficiency | 93% |
| Number of MPP trackers | 2 |
| Dimensions | 460 x 395 x 132 mm |
| Weight | 13.5 kg |
| Protection Class | IP20 (Indoor installation) |
| Communication Interfaces | Wi-Fi, USB |
| Parallel operation | Yes, up to 6 units |
| Specifications | 465W JA Solar JAM54D40 LR |
|---|---|
| Manufacturer Part Number | JAM54D40 LR |
| Max. Power | 465 watts peak |
| Module Efficiency | 23.3% |
| Number of Cells | 108 cells |
| Cell Type | Glass-Glass |
| Connection cable | 4 mm² |
| Weight | 22 kg |
| Frame height | 30 mm |
| Module width | 1,134 mm |
| Module length | 1,762 mm |
| Specifications | AXE Battery System |
|---|---|
| Battery Capacity | 5 kWh |
| Warranty | 10 years |
| Manufacturer | Growatt |
| protection rating | IP65 |
| Battery Type | Low voltage |
| Dimensions | 650 x 350 x 305 mm |
scope of delivery
- 36 x 465W JA Solar JAM54D40 LR Black Frame
- 2 x Growatt SPF 6000 ES Plus Off-Grid Inverters, including Shine Wi-Fi Stick WIFI-F
- 2 x Growatt AXE -5kW battery
- 1 x Growatt AXE battery base and cable set
